Maximum Power (4 ohms, 1kHz, 0.7% THD, for Europe) |
170 W + 170 W |
High Dynamic Power/Channel (8/6/4/2 ohms) |
120/150/200/300 W |
Damping Factor |
≧ 250 (1 kHz, 8 ohms) |
Frequency Response |
+0 /-3 dB (5 Hz-100 kHz) , +0 / -0.3 dB (20 Hz-20 kHz) |
RIAA Equalization Deviation |
+/-0.5 dB (PHONO (MM/MC)) |
Dimensions (W x H x D) |
435×180×464 mm; 17-1/8″ x 7-1/8″ x 18-1/4″ |
Weight |
24.7 kg; 54.5 lbs |
Receiver / Integrated Amplifier |
Rated Output Power |
[20 Hz-20 kHz, 0.07 %THD] 100 W + 100 W (8 ohms), 150 W + 150 W (4 ohms) |
Total Harmonic Distortion (20Hz to 20kHz) |
[Input 0.5 V] PHONO MC→LINE2 OUT: 0.02 % (1.2 mVrms), PHONO→LINE2 OUT: 0.005 % (1.2 Vrms), CD, etc./BAL1,2 →SP OUT: 0.035 % (50 W/8 ohms) |
Signal-to-Noise Ratio |
PHONO MC: 90 db, PHONO MM: 96 dB, CD, etc.: 110 dB, BAL1,2: 114 dB |
Input Sensitivity |
[1 kHz, 100 W/8 ohms] PHONO MC: 150 uVrms/50 ohms, PHONO MM: 3.5 mVrms/47 kohms, CD, etc.: 200 mVrms/47 kohms, MAIN IN: 1 Vrms/47 kohms, BAL1,2: 200 mVrms/100 kohms |
Transformer |
623 VA (Toroidal) |
